These custom instrument supports are fabricated from carbon steel with a hot dipped galvanize finish. The instrument stands vary in heights up to 5' and widths from 18" to 24". A total of 126 stands will be used to support instruments at an oil refinery. PT&P offers a complete line of adjustable and welded instrument supports in various mounting styles.
Do you see a need for instrument supports in a current or future project of yours? Get pricing today!
PT&P's field service division is available 24x7 in the case of an emergency situation or for a scheduled shut down. In this Webinar we explore the details of actual case studies focusing on various signs that indicate if a particular support needs replaced or adjusted. The presentation also covers projects that brought on new standard designs and custom designs for specific applications. And lastly, it includes valuable additions and procedures that extend the typical life span of a pipe support.
Tags: Pipe Supports Engineering & Design, Pipe Support Field Examples, Pipe Support Field Services, Expansion Joints
These custom heavy duty Fig. 43 yoke u-bolt pipe clamps are designed for manifold piping in a Continuous Catalyst Regeneration plant in Mexico. The yoke clamps are for a 36" diameter pipe size and are fabricated from A240 Grade 316 stainless steel. They are designed to support a load of 33,731 lb. and temperatures up to 1100°F. PT&P supplied a total of 16 assemblies, comprised of yoke u-bolt clamps and E-type constant springs, for this project.
Do you need yoke u-bolt clamps or constants? We would be happy to provide you with a quote today.
This presentation is on Pipe Clamps, including Hold-Down Clamps, Riser Clamps, Clevis Hangers, Yoke U-Bolt Clamps and Structural Supports. Learn how the appropriate type of pipe support is chosen based on the different design conditions. Find out how Finite Element Analysis is used in the design process and view the custom pipe supports designed for extreme applications. Finally, view the value-added services offered by PT&P and rest assure that your pipe clamp needs can be covered by our 24x7 web-based emergency services, field services and quick-turn around time when you need it most. The featured presenter, Jerry Godina has over 13 years experience as a pipe support designer and manages PT&P's engineer training development program. He also inspects existing supports, consults on site remediation projects and oversees installation on a regular basis.Tags: Structural Supports, Clevis Hangers, Yoke U-Bolt Clamps, Pipe Clamps, Riser Clamps, Hold Down Clamps, Support Assembly Components
